| Rivet diameter in inches (D) | 0.187 |
| ± diameter tolerence in inches | 0.004 |
| Maximum riveting capacity in inches (G) | 0.331 |
| Body material | Aluminum |
| Mandrel Material | Aluminum |
| Head type | CTSK 100° |
| Head diameter in inches (F) | 0.327 |
| ± Head diameter tolerence in inches | 0.018 |
| Thickness of the head in inches (H) | 0.070 |
| Thickness of the head in ± in inches | 0.005 |
| Body color | Natural |
| Tensile force in lb by rivet | 500 |
| Shear strength in lb by rivet | 600 |
| Minimum riveting capacity in inches (G) | 0.125 |
| Length of the rivet in inches (L) | 0.450 |
| Length of the rivet tolerence in ± in inches | 0.015 |
| Hole / drill required | 0.199 - #8 |
