| Rivet diameter in inches (D) | 0.250 |
| ± diameter tolerence in inches | 0.003 |
| Maximum riveting capacity in inches (G) | 0.620 |
| Body material | Aluminum |
| Mandrel Material | Steel |
| Head type | Dome |
| Head diameter in inches (F) | 0.510 |
| ± Head diameter tolerence in inches | 0.025 |
| Thickness of the head in inches (H) | 0.116 |
| Thickness of the head in ± in inches | 0.005 |
| Body color | Natural |
| Tensile force in lb by rivet | 1110 |
| Shear strength in lb by rivet | 2400 |
| Minimum riveting capacity in inches (G) | 0.520 |
| Length of the rivet in inches (L) | 0.937 |
| Length of the rivet tolerence in ± in inches | 0.015 |
| Hole / drill required | 0.257- #F |
